GN Netcom 1200 Smart Cord - The GN 1200 cord is the solution to a common problem of not being able to connect headset and telephone. Even though most things have been standardized, the cord connecting the phone with the handset or headset is anything but standard as each telephone manufacturer has its own wiring code. Now, with the universal “smart” cord, GN 1200, the cord will work with virtually any phone providing greater convenience.
Key Features:
-
Works with over 90% of all business telephones – including VoIP models
-
Offers transmit amplification when needed
-
Works with vast number of business phones that support a direct connect headset
-
Never be without the right cord even if moving to a new phone system
-
Simple slide adjustment makes for easy setup
-
7 feet of coiled cord
When hooking up a new headset there is not always a dial tone. The problem could be the headset or the telephone? But chances are it is the cord. Even though the headset and telephone may be plug compatible, the wiring is determined by the individual telephone manufacturer.
The GN 1200 Smart Cord features eight separate wire schemes – including three with built-in microphone amplification. Simply connect your headset to the GN 1200 Smart Cord quick disconnect and slide the switch, located under the panel on the side of unit, until you have a dial tone. It’s as simple as that.
These 8 switch positions and corresponding telephone systems
Jabra GN1200 Switch position |
Matching Telephone system |
Mod jack wiring |
Amplified microphone |
Equivalent GN cable |
1 |
Standard (most common), Including Polycom IP Phones |
M-, R, R, M+ |
No |
8800-01 |
2 |
Cisco IP phones 79xx series |
R, M-, M+, R |
No |
8800-02 |
3 |
Ascom office and Philips phones |
R, M+, M-, R |
No |
8800-03 |
4 |
Japanese phones, NEC , Nitsuko |
M-, R, R, M+ |
No |
8800-25 |
5 |
Plantronics Vista Base |
R, R, M+, M- |
No |
8800-02 |
6 |
Panasonic phones with modular jack |
M+, R, R, M- |
Yes |
8800-04 |
7 |
Nortel digital phones, Shoretel and Avaya IP phones** |
M-, R, R, M+ |
Yes |
8800-01 |
8 |
Avaya Callmaster V and VI, Cisco IP phones 79xx series |
R, M-, M+, R |
Yes |
8800-02 |
See GN Netcom 1200 Smart Cord Data sheet for more details
** Use the GN 1216 cable if you have the Avaya 96xx or 16xx series phone
|
