Plantronics CA12CD-S PTT Wireless Adapter 92900-01 *DISCONTINUED

plantronics ca12cd-s ptt wireless adapter 92900-01 *discontinued view

Add to Wish List

*DISCONTINUED* by Plantronics, See the new Poly CA22CD-SC PTT Wireless Adapter Single Channel (no return)

Plantronics CA12CD-S is a wireless PTT (push-to-talk) 6-wire headset adapter equipped with an analog console cable (PJ-7), designed to provide wireless encrypted communications and PTT functionality for applications such as Public Safety Dispatch and Air Traffic Control.

Key Features:

  • DECT 6.0 with 64-bit encryption
  • Operates in the UPCS band (1.92 - 1.93 GHz) in North America
  • Two charging wells (unit supplied with an extra battery)
  • Industry standard ergonomic design of PTT unit.
  • Battery recharge time: 1 hour ( 90%); 3 hours (100%)
  • Robust PTT switch with selectable locking/non-Locking operational modes.
  • Universal compatibility for carbon, electret and dynamic microphone inputs
  • Selectable output ranges for transmit and receive
  • Two (2) Lithium-Ion battery packs provide longer talk time (approximately 8 hours total) and faster recharge rates.
  • Quick Disconnect™ provides compatibility with all Plantronics “H” series headsets
  • new part# 207799-01 (previous part# 92900-01), base reads SHS2500-01

Remote Unit:

  • PTT button with momentary / locking selector
  • On-Off button with LED
  • Rugged metal belt clip
  • Receiving volume control
  • 12 inch cable with Plantronics QD (Quick Disconnect)
  • Compatible with all Plantronics H-Series Headsets

For more information and specs see Plantronics CA12CD-S datasheet and CA12CD-S Manual



What'st he difference between the old and the new Plantronics CA12CD-S?  The new CA12CD-S  has improved sound quality compared to the older CA12CD that's been around for 20+ years.  There is a second subscription button in the back of the base.  The new model also allow more units to be used in the same room without interference. There are different colored buttons on the base of the CA12CD-S and on the PTT remote units so users can easily/visually see if they have the new S model.



Important Note:  Remote and Base units from the old CA12CD will not pair with those from the CA12CD-S, The new CA12CD-S will have grey push-to-talk button to distinguish from the older CA12CD



important: see How to set CA12CD-S audio levels



Also see our Headsets for Dispatch, Emergency or Air traffic control FAQ page



Plantronics CA12CD-S parts:

Plantronics CA12CD-S replacement PTT Remote

Plantronics CA12CD battery

Plantronics CA10CD, CA12CD Console Interface Cable

Plantronics CA12CD AC/DC Wall Adapter

Plantronics CA12CD USB Adapter SSP2468-01



*Important Note on Returns: Due to the manufactures policy, this is a special order item.  All Sales are FINAL.  It's not returnable, not refundable under any circumstance.  If it's defective, Plantronics will replace it for you under warranty



This product was added to our catalog on Wednesday 03 December, 2014.
