Plantronics RD-1 Shoretel/Allworx/Toshiba Ring Sensor

The Plantronics RD-1 POD is designed for use with phones that also support native “load detect” (LD) headset hookswitch (EHS) control and works with Plantronics CS540, CS510, CS520 , Plantronics Savi WO100, Plantronics Savi WO200, Plantronics Savi WO300 Plantronics Savi WO350 , Plantronics Savi W740, Plantronics Savi W710 , Plantronics Savi W720 , Plantronics Savi W730 , Plantronics Savi W745 wireless headset families**. Once connected, the RD-1 POD will send a ringer alert signal to the headset anytime the phone rings, anywhere within a headset’s wireless range. LD hookswitch control, for telephones that support it, enables on/off-hook functions directly from the headset using the headset’s Call Control button so calls can be answered and ended remotely from the headset.

**It's also compatible with the older Plantronics Wireless headsets: Plantronics CS50, CS55, CS70N, and Voyager 510S, CS351

Key Features:

• Use the RD-1 with ShoreTel phones that support native "lead detect" (LD) headset hookswitch control (must be software version 7.0 or higher and set auto off-hook to wireless headset)

• If using software version 7.0 or higher, the RD-1 is compatible with the following ShoreTel IP phones and will not need an HL10 handset lifter for remote "hook switch": IP 212K, IP 230 (newer models only, date code must end in "GE" or "-03" or higher), IP 230g, IP 265, IP 560 (newer models only, date code must end in "GE" or "-03" or higher), IP 560G, and IP 565G.

• ShoreTel IP 110, IP 115, IP 210  older 230 and older 560 require the HL10 handset lifter instead of the ring sensor

• Also Compatible with Allworx (firmware 7.1 or higher) & Adtran phones

• Also compatible Toshiba phones are those with an HHEU headset adapter installed. Toshiba IPT2008-SDL, IPT2010-SD, IPT2020-SD, DP5000-Series Strata CIX Phone (DP5008, DP5018-S, DP5022, DP5022-SD, DP5023-SD, DP5018-S, DP5032, DSP-5118-DP, DP5122-SD, DP5130, DP5132-SD)

• 3.5mm plug inserts into bottom of Plantronics wireless headset charging base

• Ring sensor has peel stick which sticks onto the phone near the speaker to sense the ring tone when someone is calling

• Once connected, the RD-1 will send a ringer alert signal to the headset any time the phone rings, anywhere within a headset's wireless range

• Upon hearing the signal, the headset wearer presses the call control talk button on the headset to answer the call remotely

• Approximately 16" long

• 3.5mm port located on the inline box allows you to plug in an optional Plantronics Online Indicator Light (OLI) to signal to others you are busy on a call; OLI part number PL-65116-01

Old Poly part # 78887-01

New HP part # 85R71AA

Setup note: ShoreTel IP Series phones must be set to “Auto offhook Preference = Wireless Headsets in order for the wireless headset EHS (RD-1) to function when connected to the phone Headset port. When the phone is in any other Off-hook preference mode, the wireless headset will not work.

Also see Plantronics RD-1 POD user Guide
